機號 |
葉輪 |
轉速
r/min |
葉片數4 |
|
直徑
mm |
當量面積
m2 |
周速
m/sec |
| |
|
|
|
葉片角度 |
流量
m3/h |
全壓Pa |
效率
% |
軸功率
kw |
所需功率
kw |
采用電機 |
|
型號 |
功率
kw |
|
2.5 |
250 |
0.0492 |
38.0 |
2900 |
15
20
25
30
35 |
1100
1400
1740
2000
2280 |
117.7
117.7
132.4
137.3
147.2 |
0.67
0.66
0.64
0.61
0.56 |
0.053
0.070
0.094
0.116
0.148 |
0.061
0.084
0.108
0.134
0.170 |
IAO5612
IAO5612
IAO5612
IAO5622
IAO5622 |
0.12
0.12
0.12
0.18
0.18 |
|
19.0 |
1450 |
15
20
25
30
35 |
550
700
870
1000
1140 |
30.4
32.3
33.4
34.3
36.2 |
0.67
0.6
60.64
0.61
0.56 |
0.007
0.009
0.012
0.017
0.019 |
0.008
0.011
0.014
0.020
0.021 |
IAO5614 |
0.09 |
|
3 |
300 |
0.0707 |
43.8 |
2790 |
15
20
25
30
35 |
1780
2340
2780
3230
3670 |
161.9
161.9
172.7
179.5
184.4 |
0.67
0.66
0.64
0.61
0.56 |
0.120
0.160
0.208
0.264
0.336 |
0.140
0.185
0.240
0.130
0.390 |
IAO5622
IAO5632
IAO5632
IAO7112
IAO7122 |
0.18
0.25
0.25
0.37
0.55 |
|
21.8 |
1390 |
15
20
25
30
35 |
890
1170
1390
1610
1830 |
39.2
39.2
43.1
44.1
45.1 |
0.67
0.66
0.64
0.61
0.56 |
0.015
0.019
0.026
0.032
0.041 |
0.017
0.022
0.030
0.046 |
IAO5614 |
0.09 |
|
3.5 |
350 |
0.0960 |
53.1 |
2900 |
15
20
25
30
35 |
3100
3800
4800
5500
6200 |
235.4
255.1
259.9
274.7
294.3 |
0.67
0.66
0.64
0.6
0.56 |
0.295
0.391
0.508
0.637
0.805 |
0.340
0.450
0.585
0.730
0.925 |
IAO7112
IAO7122
IAO7132
IAO7132
Y802-2 |
0.370
0.55
0.75
0.75
1.10 |
|
26.6 |
1450 |
15
20
25
30
35 |
1550
1900
2400
2750
3100 |
62.8
66.7
68.7
72.6
78.5 |
0.67
0.66
0.64
0.61
0.56 |
0.040
0.051
0.069
0.084
0.108 |
0.046
0.059
0.079
0.097
0.0124 |
IAO5614
IAO5614
IAO5614
IAO5634
IAO5634 |
0.09
0.09
0.09
0.18
0.18 |
|
4 |
400 |
0.126 |
58.5 |
2800 |
15
20
25
30
35 |
4250
5570
6640
7700
8750 |
287.4
287.4
308.0
319.8
327.6 |
0.67
0.66
0.64
0.61
0.56 |
0.506
0.675
0.890
1.130
1.430 |
0.580
0.780
1.020
1.300
1.650 |
IAO7132
Y801-2
Y802-2
Y90S-2
Y90S-2 |
0.75
0.75
1.10
1.50
2.20 |
|
29.5 |
1400 |
15
20
25
30
35 |
2140
2810
3340
3880
4410 |
72.6
72.6
78.5
81.4
83.4 |
0.67
0.66
0.64
0.61
0.56 |
0.065
0.086
0.114
0.144
0.180 |
0.075
0.100
0.131
0.165
0.210 |
IAO5614
IAO5634
IAO5634
IAO5634
IAO7124 |
0.09
0.18
0.18
0.18
0.25 |
|
5 |
500 |
0.196 |
36.8 |
1410 |
15
20
25
30
35 |
4150
5450
6500
7500
8550 |
113.7
113.7
121.6
126.5
130.5 |
0.67
0.66
0.64
0.61
0.56 |
0.197
0.261
0.343
0.435
0.555 |
0.230
0.300
0.395
0.500
0.650 |
Y801-4
Y801-4
Y801-4
Y801-4
Y802-4 |
0.55
0.55
0.55
0.55
0.75 |
|
25.2 |
960 |
15
20
25
30
35 |
2780
3640
4340
5040
5730 |
51.0
51.0
54.9
56.8
57.8 |
0.67
0.66
0.64
0.61
0.56 |
0.059
0.079
0.104
0.131
0.165 |
0.068
0.090
0.120
0.150
0.190 |
Y90S-6 |
0.75 |
|
6 |
600 |
0.283 |
45.5 |
1450 |
15
20
25
30
35 |
7250
9500
11300
13150
15000 |
166.8
166.8
178.5
185.4
190.3 |
0.67
0.66
0.64
0.61
0.56 |
0.500
0.670
0.875
1.110
1.420 |
0.575
0.770
1.010
1.160
1.630 |
Y90S-4
Y90S-4
Y90S-4
Y90L-4
Y100L1-4 |
1.1
1.1
1.1
1.5
2.2 |
|
30.2 |
960 |
15
20
25
30
35 |
4800
6300
7500
8700
9900 |
73.5
73.5
78.5
81.4
83.3 |
0.67
0.66
0.64
0.61
0.56 |
0.147
0.195
0.255
0.322
0.410 |
0.170
0.225
0.295
0.370
0.470 |
Y90S-6 |
0.75 |
|
7 |
700 |
0.385 |
53.1 |
1450 |
15
20
25
30
35 |
11500
15100
1800
20900
23800 |
227.5
227.5
243.3
253.0
258.9 |
0.67
0.66
0.64
0.61
0.56 |
1.090
1.450
1.910
2.420
3.060 |
1.250
1.670
2.200
2.800
3.500 |
Y90L-4
Y100L1-4
Y100L1-4
Y100L2-4
|
1.5
2.2
2.2
3.0
|
|
35.2 |
960 |
15
20
25
30
35 |
7650
10100
12000
13900
15800 |
93.1
93.1
98.1
103.0
105.0 |
0.67
0.66
0.64
0.61
0.56 |
0.296
0.396
0.512
0.655
0.825 |
0.340
0.455
0.500
0.750
0.950 |
Y90S-6
Y90S-6
Y90S-6
Y90S-6
Y90L-6 |
0.75
0.75
0.75
0.75
1.1 |
|
8 |
800 |
0.502 |
60.7 |
1450 |
15
20
25
30
35 |
17300
22700
27000
31300
35600 |
294.2
294.2
314.0
323.4
333.2 |
0.67
0.66
0.64
0.61
0.56 |
2.110
2.810
3.680
4.620
5.900 |
2.430
3.250
4.250
5.300
6.800 |
Y100L2-4
Y112M-4
Y132S-4
Y132S-4
Y132M-4 |
3.0
4.0
5.5
5.5
7.5 |
|
40.2 |
960 |
15
20
25
30
35 |
11400
14900
17800
20600
23500 |
130.4
130.5
139.2
145.1
149.0 |
0.67
0.66
0.64
0.61
0.56 |
0.616
0.820
1.080
1.360
1.740 |
0.710
0.940
1.250
1.560
2.000 |
Y90S-6
Y90L-6
Y100L-6
Y112M-6
Y112M-6 |
0.75
1.1
1.5
2.2
2.2 |
|
9 |
900 |
0.636 |
45.2 |
960 |
15
20
25
30
35 |
16200
21200
25200
29300
33400 |
164.8
164.8
176.6
183.4
186.4 |
0.67
0.66
0.64
0.61
0.56 |
1.110
1.470
1.930
2.450
3.100 |
1.280
1.700
2.220
2.820
3.600 |
Y100L-6
Y112M-6
Y112M-6
Y132S-6
Y132M1-6 |
1.5
2.2
2.2
3.0
4.0 |
|
10 |
1000 |
0.785 |
50.2 |
1000 |
15
20
25
30
35 |
22600
29700
35400
41000
46700 |
206.0
206.0
225.4
235.4
242.3 |
0.67
0.66
0.64
0.61
0.56 |
1.930
2.580
3.460
4.400
5.600 |
2.220
3.000
4.000
5.050
6.450 |
Y112M-6
Y132S-6
Y132M1-6
Y132M2-6
Y160M-6 |
2.2
3.0
4.0
5.5
7.5 |
